|Objective Lens Diameter(mm)||20|
|Elevation/Windage Adjustment Range||>50MOA|
|Dot Size||2MOA 65MOA|
|Brightness Adjustment||12 Levels|
|Finish & Coating||Anodizing|
|Texture of Material||Aluminum Alloy|
|Size(mm)||88.2 x 70 x 38.5(LxHxW)|
1. "+" power on, power off and increase brightness.
2. "-" power on, power off and decrease brightness.
3. Press and hold the “+” or “-” button for more than 1 second to turn it on or off, and it is medium brightness when turned on.
4. Using solar energy and CR2032 battery , when the sunlight is sufficient, solar energy is preferred.
5. When power on, it will automatically shut down after 120 seconds of rest.It turns on automatically when being moved and return to the brightness of last time used.
6. 13 brightness level , 1level power on or off, other 12 Levels are Brightness Adjustment, 10 Level DAY-mode, 2 Level Night-mode.
7. Reticle mode(Circle dot),Dot size:2MOA;Reticle size:65MOA.
8. MIL-STD 1913 Rail
9. 30min@1m deepness Waterproof; Fog-proof.
10. T10 Wrench tool
