| Magnification : |
4.5x-14.5x |
| Objective Lens Diameter : |
50mm |
| Specification : |
4.5-14.5X50 |
| Reflex Lens Coating : |
Multilayer Broadband Transparent Film |
| Overall Light Transmission : |
>85% |
| Parallax : |
<1MOA |
| Parallax Correction : |
100M |
| Field Angle : |
5.3-1.65 |
| Exit Pupil Diameter : |
12-4.0mm |
| Distance of Exit Pupil : |
2.64-3.19 |
| Click Value : |
1/4" |
| Focusing Range : |
5-infinity |
| Adjustment Type : |
Outside Adjust |
| Spiral Direction : |
Clockwise |
| E/W Adjustment Range : |
±30-±40 |
| Reticle : |
Mil-Dot |
| Illuminated Reticle : |
Red/Green ,6 levels of brightness |
| Resistance : |
3.5KG |
| Finish & Coating : |
Anodic Oxidation |
| Color : |
Matte Black |
| Texture of Material : |
Aluminum Alloy |
| Marking : |
According to the demend of client |
| Length*Height*Width : |
380mm*60mm*75mm |
| Weight : |
667g |
| Operation Temperature Range : |
-30℃~ +50℃
|
| Storage Temperature Range : |
-50℃~ +70℃ |
| Mounting Styie : |
Picatinny rail |
| Battery : |
CR2032 |
| Battery Life : |
3000/ the 4th level |
| Power Supply : |
3V |
