1.This 4X32 night vision scope is designed for day and night use, allowing you to see clearly in the dark.
2.It is lightweight and easy to carry, making it ideal for outdoor activities.
3.The 4X magnification and 32mm objective lens provide a wide field of view of 6.68°x5.0°, allowing you to observe your target from a distance.
4.The exit pupil distance of 14mm and exit pupil diameter of 6mm provide a clear and sharp image.
5.The range of visibility adjustment is ±5 SD, allowing you to adjust the brightness of the image to suit your needs.
|
class
|
projects
|
4X The parameter value
|
|
Optical performance
|
magnification
|
4X
|
|
Diameter of the objective
|
Φ32mm
|
|
Field of view(FOV)
|
6.68°x5.0°
|
|
Exit pupil distance
|
14mm
|
|
Exit pupil diameter
|
6mm
|
|
Range of visibility adjustment
|
±5 SD
|
|
Points braid rate
|
5.6″
|
|
Minimum observation distance
|
0.8m
|
|
Observe the distance at night
|
more that 200m
|
|
imager
|
The sensor
|
1/3″CMOS
|
|
Horizontal definition
|
420 lines
|
|
Display unit
|
Display device
|
0.24inch LCOS
|
|
resolution
|
300(H)*224(V)
|
|
lighting
|
Lighting devices
|
IR LED
|
|
Center wavelength
|
940nm
|
|
Power supply
|
Working voltage
|
DC 3V
|
|
Built-in power supply
|
2 section 5 battery
|
|
The battery works continuously
|
1.5/2.5 h(IR ON/IR OFF)
|
|
Product size
|
Length * width * height
|
13.5X6.3X6.4CM
|
|
Packing size
|
Length * width * height
|
20.6X17.5x8.2CM
|
|
others
|
switch
|
1. Power switch;
2. Infrared illumination brightness adjustment;
3. Forced switch infrared illumination
|
|
weight
|
214g (without battery) 261g (with battery)
|
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Night Vision is a precision electronic instrument used to observe the target in the night and twilight.
In order to meet in a very low light intensity, night vision with infrared irradiation light source, turn on the power switch, you can adjust its brightness by switching.
OP-168 is a day and night of night vision comes with infrared the irradiated light source.
Under bright and dim light it shows color lmages while black and white image in darkness.
OP-168 own infrared irradiation light source device,according to the use of environmental condition can be forced open or close, and may, according to the environment light brightness manual regulation to need the best condition.
Night-vision equipment can be split into three broad categories:
Scopes - Normally handheld or mounted on a weapon, scopes are monocular (one eye-piece). Since scopes are handheld, not worn like goggles, they are good for when you want to get a better look at a specific object and then return to normal viewing conditions.
Goggles - While goggles can be handheld, they are most often worn on the head. Goggles are binocular (two eye-pieces) and may have a single lens or stereo lens, depending on the model. Goggles are excellent for constant viewing, such as moving around in a dark building.
Cameras- Cameras with night-vision technology can send the image to a monitor for display or to a VCR for recording. When night-vision capability is desired in a permanent location, such as on a building or as part of the equipment in a helicopter, cameras are used. Many of the newer camcorders have night vision built right in.
Night-vision devices were first used in World War II and came into wide use during the Vietnam War.The technology has evolved greatly since their introduction, leading to several "generations" of night-vision equipment with performance increasing and price decreasing. Consequently, they are available for a wide range of applications, e.g. for gunners, drivers and aviators.
