| Electron Magnification |
1x-8x |
| Optical Magnification |
1x |
| Field of View(FOV) |
21.5°x12° |
| Objective Parameters |
19.58mm / F1.2 |
| Sensor |
0.0001LUX Ultra low illumination black and white sensor |
| Display |
1920x1080 OLED display |
| Exit Pupil Diameter |
7.0mm |
| Pupillary Exit Distance |
27mm |
| Auxiliary Llight Source |
850nm Infrared light |
| Image Display Mode |
Three colors: black/white, red and green |
| Screen Brightness |
Level 1-7 is adjustable |
| Luminance of the Iinfrared Lamp |
Level 1-5 is adjustable |
| Cross Dividing Line |
Six modes, red, green, black three color choice |
| Date and Time Setting |
yes |
| Video Function |
yes |
| Memory Card |
8GB-128GB TF (Optional capacity) |
| Waterproof |
IP65 |
| External Interface |
Type-c |
| Cable |
Typle-cable |
| WIFI |
Equipped with APP, compatible with iOS and Android system mobile phones |
| Electronic Compass |
All directions indication |
| Electronic Gyroscope |
Pitch Angle roll Angle dynamic display |
| Interface to Flip |
0°-108°be interchangeable |
| Mechanical Interface Dovetail |
Optional to fit two tactical helmet tipper mounts,can switch between left and right eyes. |
| Working Time |
Use a 16340 rechargeable battery, continuous working time is more than 1h (infrared light on), 1.5h(infrared light off); Use a 16650 rechargeable battery, continuous working time is more than 3h(infrared light on), 4.5h(infrared light off) |
| Battery Type |
1 16340 rechargeable battery or 1 16650 rechargeable battery |
