Magnification :
|
2.5x-10x
|
|
Objective Lens Diameter :
|
26mm
|
|
Specification :
|
2.5-10X26
|
|
Reflex Lens Coating :
|
Multilayer Broadband Transparent Film
|
|
Overall Light Transmission :
|
>85%
|
|
Parallax :
|
<1MOA
|
|
Parallax Correction :
|
100M
|
|
Field Angle :
|
8-2.4
|
|
Exit Pupil Diameter :
|
10-2.6mm
|
|
Distance of Exit Pupil :
|
2.64-3.20
|
|
Click Value :
|
1/4"
|
|
Focusing Range :
|
5-infinity
|
|
Adjustment Type :
|
Outside Adjust
|
|
Spiral Direction :
|
Clockwise
|
|
E/W Adjustment Range :
|
±30-±40
|
|
Reticle :
|
Mil-Dot
|
|
Illuminated Reticle :
|
Red/Green ,6 levels of brightness
|
|
Resistance :
|
3.5KG
|
|
Finish & Coating :
|
Anodic Oxidation
|
|
Color :
|
Matte Black
|
|
Texture of Material :
|
Aluminum Alloy
|
|
Tube Diameter :
|
30mm
|
|
Marking :
|
According to the demend of client
|
|
Length*Height*Width :
|
290mm*60mm*75mm
|
|
Weight :
|
523g
|
|
Operation Temperature Range :
|
-30℃~ +50℃
|
|
Storage Temperature Range :
|
-50℃~ +70℃
|
|
Mounting Styie :
|
Picatinny rail
|
|
Battery :
|
CR2032
|
|
Battery Life :
|
3000/ the 4th level
|
|
Power Supply :
|
3V
|
|
RED DOT Performance Parameter
|
|
Magnification
|
1x
|
|
Reflex Lens Coating
|
Red
|
|
Overall Light Transmission
|
85%
|
|
Objective Lens Diameter
|
22X16.5
|
|
Reticle Style
|
Single dot
|
|
Dot Size
|
2MOA
|
|
Parallax
|
1.5
|
|
Parallax Correction
|
50M
|
|
Adjustment Turrets
|
Hexagon
|
|
Adjustment Range
|
45MOA
|
|
Pressure of adjustment screw
|
2kg
|
|
Brightness
|
04 Level
|
|
Whock resistance
|
1000G
|
|
Waterproof
|
5m
|
|
Apperance Parameter
|
|
Centerline Height
|
22MM
|
|
Finish & Coating
|
Anodizing
|
|
Color
|
MATTED BLACK
|
|
Marking
|
Can be customized
|
|
Length
|
46MM
|
|
Height
|
37MM
|
|
Width
|
31MM
|
|
Weight
|
62g,with batteries
|
|
The use of parameters
|
|
Resistance
|
1100g
|
|
Mounting Requirement
|
21.2MM
|
|
Mounting Styie
|
ScrewBriquetting way
|
|
Ooperation temperature range
|
1-20~+60(there will be a change of the battery)
|
|
Storage temperature range
|
1-20~+60(there will be a change of the battery)
2-20~+75 (without battery )
|
|
Mounting Styie
|
Screw,Briquetting way
|
|
Battery
|
CR2032(225mAH)
|
|
Battery Life
|
High-light:50 hours,Low-light:500 hours
|
|
Power supply
|
3V
|
|
Operating current(low-light)
|
0.3mA
|
|
Operating current(high-light)
|
3.5mA
|
|
Quiescent Current
|
1A
|
|
Rated Input Power
|
10mW
|
|
Rated input voltage
|
3.0V
|
|
Rated Input Current
|
3.5mA
|
|
Rated Output Voltage
|
3.0V
|
|
Rated output current
|
3.5mA
|
|
Frequency
|
82Hz
|
Rifle scope
Rifle scope includes telescopic sight, collimating optical sight, and reflex sight.The telescopic sight and the reflex sight are the most popular, and used at day, also name day scope/day sight. In additional, if we add night vision on the day scope, it's called scope/night sight.
A telescopic sight, is asighting device that is based on an optical refracting telescope. They are equipped with some form of graphic image pattern (a reticle) mounted in an optically appropriate position in their optical system to give an accurate aiming point. Telescopic sights are used with all types of systems that require accurate aiming but are most commonly found on fire arms, particularly rifles. Other types of sights are iron sights, reflector (reflex) sights, and laser sights.
Product Scope of Application
1. CS and wargame
An advantage of using a scope with your rifle or gun is that you will be able to aim at your target easier. Also, it is much easier to lineup the target in the crosshairs of a high-quality scope than it is with a standard iron sight. You can feel more confident when using a scope under a high-pressure situation where you need to hit your target. Over time, your ability to leverage the scope to its full potential will be better, which will make you a good shooter
2. Hunting and shooting pratice
Imagine if you have a sophisticated scope attached to your rifle. It would look like you could do no wrong – if it was a high pressure shooting situation, you’d be getting hit after hit. This is the kind of feeling which a rifle scope instills in the shooter. It magnifies the target so you’re able to choose exactly where you want to aim your shot! Ultimately, you feel in control of the entire situation
3. Military
As you get better at shooting with your rifle, you will want to shoot farther and with better accuracy. Soon, shooting at targets from your normal sights just will not do anymore – and that’s when you’ll know you need a quality rifle scope. Since it brings the targets much closer in your vuew, you’re able to aim and hit targets farther out. In fact, modern scopes let you change their ocular settings to match your eyes so you don’t have to deal with your glasses in the field!
