| Magnification |
4X -16X |
| Objective Lens Diameter |
40mm |
| Specification |
4-16X40AOL |
| Reflex Lens Coating |
Multilayer Broadband Transparent Film |
| Overall Light Transmission |
>85% |
| Parallax |
<1MOA |
| Parallax Correction |
100YDS |
| Exit Pupil Diameter |
10-2.5mm |
| Distance of Exit Pupil |
3.5-3.9 |
| Click Value |
1/4" |
| Focusing Range |
10-infinity |
| Adjustment Type |
Outside Adjust |
| Spiral Direction |
Clockwise |
| E/W Adjustment Range |
±30-±40 |
| Reticle |
Mil-Dot |
| Illuminated Reticle |
Red/Green/Blue ,4 levels of brightness |
| Resistance |
3KG |
| Finish & Coating |
Anodic Oxidation |
| Color |
Matte Black |
| Texture of Material |
Aluminum Alloy |
| Tube Diameter |
25.4mm |
| Marking |
According to the demend of client |
| Length*Height*Width |
369.7mm*65mm*70.5mm |
| Weight |
660g |
| Operation Temperature Range |
-30℃~ +50℃ |
| Storage Temperature Range |
-50℃~ +70℃ |
| Mounting Styie |
Picatinny rail |
| Battery |
CR2032 |
| Battery Life |
3000/ the 2nd level |
| Power Supply |
3V |
