| product description: |
3-9X40 |
|
| Performance Parameter |
|
| (image quality requirement) |
distinguishability≤7.5 |
| (parallax) |
±5% |
| (reticle displacement) |
≤1MOA |
| (FOV) |
0.5D |
| (adjust screw) |
Separate regulating scope ≤1MOA |
| (exit pupil ) |
15.2mm |
| (view of angle) |
21.2° |
| (reticle) |
second |
| (Magnification) |
3X-9X |
| (Specification) |
3-9X40 |
| (Reflex Lens Coating) |
Purple membrane |
| (Overall Light Transmission) |
88.21% |
| (Objective Lens Diameter) |
40 |
| (fieldangle) |
37.68ft-12.36ft |
| (Parallax) |
+2/-2 |
| (Parallax Correction) |
100yds |
| (Exit pupil diameter/mm) |
13.33mm-4.44mm |
| (distance of exit pupil) |
96.5mm-111.7mm |
| (Focusing range) |
NA |
| (Adjustment Type) |
inside |
| (Click Value) |
1/4” |
| (Spiral Direction) |
clockwise |
| (elevation/windage adjustment range)： |
±30MOA |
| Reticle |
BDC
|
| Reticle Lighting Brightness |
NA |
| (resistance)： |
NA |
| Apperance Parameter |
|
| (Finish & Coating) |
Anodize |
| (Color) |
Black Matte |
| (Texture of material)： |
6063 |
| (Tube diameter) |
25.4 |
| (Marking) |
according to you |
| (Length) |
310mm |
| (Height) |
55.6mm |
| (Width) |
55.6mm |
| (Net Weight) |
420g |
| Physical Properties |
|
| (impact) |
900G,20times |
| (fog-proof) |
-30℃，20minutes，10 minutes disappear |
| (water-proof) |
52℃ 40m deep，3min |
| (repeat clamp reticle displacement) |
|
| (reticle displacement after the shock) |
1MOA |
| (operation temperature range): |
-30℃ to 60℃ |
| (storage temperature range)： |
25℃ |
