Performance Parameter |
(image quality requirement) |
distinguishability≤9.4 |
(parallax) |
±5% |
(reticle displacement) |
≤1MOA |
(FOV) |
0.5D |
(adjust screw) |
Separate regulating scope ≤1MOA |
(exit pupil ) |
20mm |
(view of angle) |
18.5° |
(reticle) |
second |
(Magnification) |
2X-7X |
(Specification) |
2-7X32 |
(Reflex Lens Coating) |
Purple membrane |
(Overall Light Transmission) |
88.50% |
(Objective Lens Diameter) |
32 |
(fieldangle) |
46.98ft-13.2ft |
(Parallax) |
+2/-2 |
(Parallax Correction) |
100yds |
(Exit pupil diameter/mm) |
14.46mm-4.57mm |
(distance of exit pupil) |
99mm-119mm |
(Focusing range) |
NA |
(Adjustment Type) |
inside |
(Click Value) |
1/4” |
(Spiral Direction) |
clockwise |
(elevation/windage adjustment range): |
±30MOA |
Reticle |
BDC |
Reticle Lighting Brightness |
NA |
(resistance): |
NA |
Apperance Parameter |
(Finish & Coating) |
Anodize |
(Color) |
Black Matte |
(Texture of material): |
6063 |
(Tube diameter) |
25.4 |
(Marking) |
according to you |
(Length) |
292.6mm |
(Height) |
51.6mm |
(Width) |
51.6mm |
(Net Weight) |
405g |
Physical Properties |
(impact) |
900G,20times |
(fog-proof) |
-30℃,20minutes,10 minutes disappear |
(water-proof) |
52℃ 40m deep,3min |
(repeat clamp reticle displacement) |
|
(reticle displacement after the shock) |
1MOA |
(operation temperature range): |
-30℃ to 60℃ |
(storage temperature range): |
25℃ |
