|Reflex Lens Coating||Red film|
|Objective Lens Diameter||20|
|Adjustment Type||manual adjustment|
|Elevation/windage adjustment range||>120MOA|
|Coordinate lighting brightness||6 Levels|
|Finish & Coating||Anodizing|
|Texture of material||Aluminum alloy|
|Marking||According to the customer request|
|The use of parameters|
|Operation temperature range|
|-20℃~+60℃(-20Come with battery , low temperature may not reach 20degree|
|Storage temperature range|
|1.-20℃~+60℃(-20Come with battery , low temperature may not reach 20degree|
|Mounting Styie||bolt,the way of briquetting|
|Battery||AAA AAA Batterythis battery is not chargeable) or can buy the chargeable battery by yourself|
|High light||15hours Low light|
|Charging currentstrong sunlight||25mA|
|Rated Input Power||100mW|
|Rated input voltage||1.5V|
|Rated Input Current||65mA|
|Rated Output Voltage||3V|
|Rated output current||30mA|
1, The product adopted the AAA battery with 1.5V and the solar battery (the inner voltage is 3.3V) . We can choose the solar battery for charge first and it can charge for the battery in the same time . The battery will work automatically if the solar power is not enough .
2, The solar power is chargeable for the battery ,even the switch is turned off .
3, There are two switches including the “↑” and “↓”.
4, “↑”is the switch for turning on and adjustment of the increasing brightness .When you touch the button “↑”which show the defaulted lowest brightness . The brightness will increasing when you press the button “↑” time by time .The most brightest state is on 6class ,when you press the button “↑” more than 6times ,nothing will be changed.
5, The button “↑” is used for lowering down the brightness and turning off . The brightness will lowered down by pressing the “↑”time by time .It will be off state when you press more time on it and it is on the lowest brightnes.
